$86.03

iStarUSA BPU-230SATA - 2x5.25" to 3x3.5" SAS/SATA 6.0 Gb/s Hot-Swap Cage (Black)
[BPU-230SATA-BLACK]

  • BPU-230SATA-BLACK
  • BPU-230SATA-BLACK
  • BPU-230SATA-BLACK
  • BPU-230SATA-BLACK
  • BPU-230SATA-BLACK
  • BPU-230SATA-BLACK
  • BPU-230SATA-BLACK
  • BPU-230SATA-BLACK
  • Stylish aluminum color handle and heat-sink body
  • Aluminum Design with Conductive Dissipation Grooves
  • Power, fan and high temperature LED indicators
  • High Performance Transfer Rate up to 6.0 Gb/s
  • Equipped with Fan Speed Control Switch
  • 3TB Hard Drives Compatible
Video Button

Click the close button to return to the web page.

Stock Status: Stock Available



Click here for a quote

  • Stylish aluminum color handle and heat-sink body
  • Support Hot-Swap & RAID Configuration (need an additional RAID controller)
  • Aluminum Design with Conductive Dissipation Grooves
  • Power, fan and high temperature LED indicators
  • Super Air Ventilation & Heat Sink with 70mm Fan
  • High Performance Transfer Rate up to 6.0 Gb/s
  • Support 3.5" SAS I/II & SATA I/II/III HDDs
  • Support 2.5" SAS I/II & SATA I/II/III HDDs
  • Equipped with Fan Speed Control Switch
  • 3TB Hard Drives Compatible
    Create more space for hard drive with hot-swap capability, BPU-230SATA series supports RAID 1/0/1+0/5 configuration for high performance or redundancy data application. Aluminum construction provides light weight but strong stability and extra 70mm fan keep hard drive at maximum performance.
    High density multi-disk storage backplane that allows multiple 3x3.5" SAS/SATA hard drives to be mounted into 2 standard 5.25". Aluminum construction provides best heat dissipation required for high performance SAS/SATA drives, is designed with excellent front to back vent airflow.
    Applications: Digital Audio Editing,Video Editing (SD or HD),Security System,SOHO SMEs With Limit HDD Tray and Data Protection or Disk-to-Disk Backup
Model NumberBPU-230SATA
RoHS Compliance VersionYes
Standard Drive Bays5.25" Drives: 2
Hotswap 3.5: 3
Hotswap HDD Type:3.5" SAS I/II & SATA I/II/III
IndicatorsPower, HDD, fan, and high temperature
Material of HandleAluminum
Material of Main ChassisAluminum Design with Conductive Dissipation Grooves
Cooling Fan1x 70mm
Dimensions (WxHxD)5.75" x 3.39" x 7.95"
146.1 mm x 86.1 mm x 201.9 mm
Packing Box (WxHxD)5.75" x 3.39" x 7.95"
146.00 mm x 86.00 mm x 202.00 mm
G.W. of Packing Box (kg)1.4 kg
Carton ( WxHxD )14.96" x 11.02" x 20.47"
380.00 mm x 280.00 mm x 520.00 mm
G.W. of Carton (kg)14.2 kg
